NRF24L01+PA+LNA Wireless Module With Antenna 1000 Meters Long Distance FZ0410
NRF24L01+PA+LNA Wireless Module With Antenna 1000 Meters Long Distance FZ0410
Couldn't load pickup availability
SPECIFICATIONS
Brand Name: EYEWINK
Choice: yes
Condition: New
High-concerned chemical: none
Model Number: NRF24L01+PA+LNA wireless modules
Origin: Mainland China
Package: SMD
Supply Voltage: 3-3.6V
Type: Module
is_customized: Yes
Description:
-
-
Voltage: 3-3.6V
Max output power: +20 dBm
Working current in transmit mode: 115mA
Working current in receiver mode: 45mA
Current in mode: 4.2uA
Operating temperature: -20-70 degree
Receiver sensitivity: -92dBm in 2Mbps mode, -95dBm in 1Mbps mode, -104dBm in 250kbps mode
PA growth: 20dB
LAN growth: 10dB
LAN noise figure: 2.6dB
Antenna growth: 2dBI
2M rate: 520m
-
Package Included: Original details of picture
